MITUTOYO 331-351 0-1" IP65 Digital Spline Micrometer

€395.00 Ex. VAT

Code Range Type No. Quantity Price Ex. VAT
012868 0-1'' 331-351 €395.00
Add to Basket
Delivery Info

Free delivery on all orders over €49.99 + VAT, Click here for more information

Returns Policy
Click to view complete product details

Mitutoyo 331-351 0-1" IP65 Digital Spline Micrometer



The Mitutoyo 331-351-30 Digital Spline Micrometer has a Measuring Range of 0-1"/ 25.4 mm and is a Type A model. This series features a small diameter Anvil and Spindle for measuring splined shafts, slots and keyways. Equipped with a Ratchet Stop for constant force, IP65 Protection against dust and water as well as SPC data output.

The Mitutoyo digital micrometer is a device that uses a calibrated screw in conjunction with integrated callipers to accurately measure very small distances and is widely used in industries such as mechanical engineering and machining.

At Caulfield Industrial, we know that when it comes to measuring tools such as these, you can never compromise on the quality of the tool used. That is why we stock tools from Mitutoyo, one of the leading manufacturers of micrometers in the world. Feel free to browse our entire selection measuring devices online before purchasing your own Mitutoyo digital micrometer today.

Features:
  • This Digimatic Spline Micrometer makes it easy for you to measure grooves and shaped parts
  • Stepped measuring surfaces
  • Suitable for measuring grooves, splined shafts, recesses, shaped parts, etc
  • Scale thimble and sleeve satin chrome finish, diameter 18 mm
  • Measuring surfaces carbide tipped, micro-lap finish, stepped
  • Auto power off after 20 minutes non-use
Specifications:
  • Range: 0-1"
  • Accuracy: ±2 µm/0.0001"
  • Digital Step: 0.001 mm
  • Flatness: 0.3 µm/0.000012"
  • Measuring Spindle (Spindle Lock): 6.35 mm
  • Measuring Spindle (Spindle Pitch): 0.5 mm
  • Battery Life: Approximately 2.4 years
  • Function Lock: Yes
  • Data Output: Yes
  • Length: 58.2 mm
  • Weight: 0.330 kg
Includes:
  • Box, setting standard (from 25 mm upward), key, 1 battery
